The trapezoidal annular guide rail circulation conveyor system, integrated with a base plate structure, provides versatile operational configurations and high positioning accuracy. It can be customized as an alternative to traditional rotary table conveying systems, effectively addressing the requirements of high-precision and irregular-shaped workpiece circulation applications.

Structural Features

Shape-Trapezoidal

Base structure

Precision chain drive

Non-standard customization description

* Commonly used Circular guideway diameter is 255~600 mm, the parameter table of the Circular guideway can refer to our《GMP Series Products》.

* We provide 25 mm, 44 mm, 76 mm these three specifcations of guide rail for you to choose.

* Speed is related to load size, circular guideway size and off-load condition.

* The Angle of the turn and the shape of the line body can be customized according to the need to communicate.

* Optional ranges of repeated positioning accuracy are:±0.05-±0.5 mm
